Compact One

Features and scenarios

  • 4x Zoom

    Designed with huddle rooms in mind, the 4x lossless zoom provides crisp, clear imagery at full HD resolution - even when fully zoomed in.

  • Metal housing

    CNC machined with a fingerprint-proof, anodized matte surface finish. We haven't tested to see if it's actually bulletproof, but we wouldn't bet against it.

  • Exceptional Outputs & Controls

    Connects via USB-B. Controlled via RF remote control. Zoom in, zoom out, change the brightness, make it sharp, make it rough, or hand over the image settings to the automatic adjustment program. The power is in your hands.

  • Group Framing

    Let the Compact One do the work with group auto-framing. As people join your meeting the camera will automatically adjust to get everyone in the picture.

  • Plug and Play

    Enjoy a seamless experience with your go-to video conferencing app. One cable gives you audio and video. Plug it into a USB-B port and you're good to go!

Compact One-0
Compact One-0
Compact One-0
Compact One-0
Compact One-0
Compact One
  • Model
  • ACO-01
  • Product
  • 4K USB Webcam
  • Measurements
  • 115mm x 36mm x 60mm
  • Image Sensor
  • 1/2.8 inch
    Effective pixels: 8 megapixels
  • FOV
  • 120° allow  + - 2°tolerance
  • Interface
  • USB-B
  • ISP
  • AE, AWB, AGC
  • Video Resolution
  • MJPG:
    3840*2160@30fps; 2560*1440@30fps,1920*1080@30fps; 1280*720@30fps; 1024*576@30fps; 640*480@30fps
    H.264、H.265::
    3840*2160@30fps; 2560*1440@30fps; 1920*1080@30fps; 1280*720@30fps; 1024*576@30fps; 640*480@30fps
    YUY2、NV12:
    1280*720@15fps; 1024*576@20fps; 640*480@30fps
  • Video Formats
  • MJPEG, YUY2, H.264, H.265、NV12
  • Driver
  • Driver-free, “in box” UVC1.5
  • Parameter settings
  • Brightness, contrast, Saturation, Sharpness, AWB,
    Gamma, Exposure, Backlight Compensation, Gain
  • Microphone
  • 2 x microphones
    Pick up range: Maximum 6 meters, suggested 1 to 2 meters for optimal quality
    Encoding Format: PMC
  • Tripod compatible
  • Yes
  • Auto-framing
  • Yes, on chip
  • ePTZ tracking
  • Yes, on chip
  • Control
  • UVC Zoom Rooms, IR remote, Angekis desktop app
  • Working current
  • 100mA - 150mA
  • Operating temperature
  • -10°C to 50°C
  • Storage temperature
  • -40°C to 70°C
  • System compatibility
  • Windows / Mac OS / Linux / Full HD or 4K at MJPG, H.264
    Android (may only use YUY2 VGA)
  • Weight
  • Approximately 370 grams
  • Privacy Cover
  • Yes
